| Function | |
|---|---|
| Contact Arrangement | 2X 1C (DPDT(B-M)) (H-Bridge) |
| Contact Current | 25Amotor lock (14VDC) |
| Max. Switching Power | 480W |
| Max. Switching Voltage | 16VDC |
| Contact Resistance or Voltage drop | < 250mV (at 10A) |
| Electrical Operations | |
| Mechanical Operations | |
| Sizing (mm) | 14.5X14.1X14.0 |
