Find out more about our RJS1N1- 16, push button anti-vandal switches. Durable and easy to assemble, available without LED illumination custom options available and switch head types.
For LED illumination options, see RJS1N1-16L
Key Features:
Switch head type:
Choose from high head/ ball head/ flat head. The centre of the push button switch will be either raised, concave or flat, depending on your preference.
Customisation:
Power symbol: C5 denotes that our 16mm, anti-vandal switches have a power symbol. The power symbol can be illuminated or etched or stamped. The choice is yours.
Custom etching and Stamping: Our 16mm push button switches can support a range of custom etching and stamping.
Wiring: Would you like wiring with your switches? Speak to our Sales Engineers, let’s discuss the options.
Metal finishes Our 16mm, anti-vandal push button switches can be available in a range of metal finishes from brass, gold-finishing, red, green or black.
See more on our custom page, for more information on customisation, speak to our Sales Engineers direct.
Configuration:
Many of our anti-vandal switches are 1NO1NC or 2NO2NC also referred to as SPST or DPDT.
We have a range of non-illuminated electromechanical and Push Button switches that support a range of poles and throws. Our switches are commonly referred to as single pole and double pole which relates to the number of circuits that are controlled by the switch. The throw defines how many positions the switches poles can be connected to.
Switch Configurations:
A normally open (NO) switch has contacts that are open or disconnected in their unactuated (normal) position. A normally closed (NC) switch has contacts that are closed or connected in their unactuated (normal) position.
The switches are electrical switches available in different configurations including two-position On/Off, three-position, momentary, maintained and more.
Momentary ON – describes contacts that interrupt the circuit when the switch is in the normal, open (NO) position.
Momentary OFF – describes contacts that establish a circuit when the switch is in the normal, closed (NC) position.
Alternate ON/OFF – describes a switch where the first actuation turns the switch ON and the second actuation turns the switch OFF.
IP Rating:
Many of our push button switches and electromechanical components are IP rated.
For more information on IP Rating, see our blog post.
IP Rating: Our non-illuminated electromechanical and Push Button switches are IP rated (from the front) which means that our switches are sealed and/or waterproof, making them hardwearing and durable in a range of conditions.
Let us give you a break down of the IP ratings. Click to save or screenshot the table, for future reference. Many of our PCB and panel mount switches are IP rated. For more information about IP ratings, click to read our blog about IP rating.
IP65 Rated
Dust-tight, protected against water projected from a nozzle.
IP66 Rated
Dust-tight and protected against powerful water jets.
IP67 Rated
Dust-tight, protected against water immersion for 30 minutes between depths of 150mm to 1000mm
IP68 Rated
Dust-tight and protected against continuous water immersion.
Applications:
Our RJS1N1-16, anti-vandal switches are ideal for a range of domestic and commercial applications suited for many industries. Especially equipment and devices designed for domestic and commercial vehicles, door entry and security, coffee machines, elevators, traffic light equipment, medical and communication devices.
